عربىHKR-2-400 Return Roller/KR
Cat:Return Roller/KR
Support roller of belt return for two trough. Model Width of belt d e m A H B n axb HKR-2-400 4...
See Details
Product
-
Support roller of belt return for two trough.
Model Width of belt d e m A H B n axb HKR-2-400 400 89.1 460 640 690 110 110 60 15x25 HKR-2-450 450 89.1 510 690 740 110 110 60 15x25 HKR-2-500 500 89.1 560 740 790 110 110 60 15x25 HKR-2-600 600 89.1 660 840 890 110 110 60 15x25 HKR-2-750 750 114.3 850 1040 1090 110 110 60 15x25 HKR-2-900 900 114.3 1000 1190 1240 110 110 60 15x25
-
KSR-400 Spiral carrier Roller/KSR
Cat:Spiral Carrier Roller/KSR
Spiral scraper is used for ridding up attachments which can cause deformation of belt and protect da...
See DetailsSpiral scraper is used for ridding up attachments which can cause deformation of belt and protect damage of roller.
Model Width of belt d e m A H B n O axb KSR-400 400 100 460 640 690 110 120 60 14.5 15x25 KSR-450 450 100 510 690 740 110 120 60 14.5 15x25 KSR-500 500 100 560 740 790 110 120 60 14.5 15x25 KSR-600 600 100 660 840 890 110 120 60 14.5 15x25 KSR-750 750 115 850 1040 1090 110 120 60 14.5 15x25 KSR-900 900 115 1000 1190 1240 110 120 60 14.5 15x25 KSR-1050 1050 142 1150 1340 1390 130 150 100 19 15x25 KSR-1200 1200 142 1300 1490 1540 130 150 100 19 15x25 KSR-1400 1400 166 1530 1730 1790 160 180 120 23 18x30 KSR-1600 1600 166 1730 1930 1990 160 180 120 23 18x30
-
Carrier Roller & Return Roller/CR & RR
Cat:Spiral Carrier Roller/KSR
Japanese specification JS is corresponding with B-8803.This is standard specification and size, spe...
See DetailsJapanese specification JS is corresponding with B-8803.
This is standard specification and size, special size can be made as your request. Please attach more detail specifications of all parts.Model Width of belt D e1 e2 e3 a e d CR-400 400 89.1 145 153 175 8 14 20 CR-450 450 89.1 165 173 195 8 14 20 CR-500 500 89.1 180 188 210 8 14 20 CR-600 600 89.1 210 218 240 8 14 20 CR-750 750 114.3 265 273 295 8 14 20 CR-900 900 114.3 315 323 345 8 14 20 CR-1050 1050 139.8 370 380 410 11 18 25 CR-1200 1200 139.8 420 430 460 11 18 25 CR-1400 1400 165.2 500 510 540 11 22 30 CR-1600 1600 165.2 580 590 620 11 22 30 CR-1800 1800 165.2 650 660 690 11 25 35 CR-2000 2000 165.2 730 740 770 11 25 35 Model Width of belt D e1 e2 e3 a e d RR-400 400 89.1 460 480 505 8 14 20 RR-450 450 89.1 510 530 555 8 14 20 RR-500 500 89.1 560 580 605 8 14 20 RR-600 600 89.1 660 680 705 8 14 20 RR-750 750 114.3 850 880 905 8 14 20 RR-900 900 114.3 1000 1030 1055 8 14 20 RR-1050 1050 139.8 1150 1180 1215 11 18 25 RR-1200 1200 139.8 1300 1330 1365 11 18 25 RR-1400 1400 165.2 1530 1550 1585 11 22 30 RR-1600 1600 165.2 1730 1750 1785 11 22 30 RR-1800 1800 165.2 2000 2040 2075 11 25 35 RR-2000 2000 165.2 2200 2240 2275 11 25 35
-
Single Row Sprocket Drive Roller
Cat:Sprocket Drive Roller
Type Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket d d2 A B...
See DetailsType Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket d d2 A B W1 BB KR-384010S 38.1×2.3 100~800 STKM 6001ZZ · 6201Z 12.0 18×12.2×26 #40×10TS 46 41.1 12 14 W-1 W+28 KR-424010S 42.7×2.3 100~800 STKM 6001ZZ · 6201Z 12.0 18x12.2×26 #40×10TS 46 41.1 12 14 W W+28 KR-484010S 48.6×3.5 100~800 SGP40A 6001ZZ · 6201Z 12.0 18×12.2×26 #40×10TS 46 41.1 12 11 W+5 W+28 KR-504010S 50.8×1.6 100~800 STKM 6001ZZ · 6201Z 12.0 18×12.2×26 #40×10TS 46 41.1 12 13 W-1 W+28 KR-574010S 57.1×2.1 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×26 #40×10TS 46 41.1 12 13 W W+28 KR-604010S 60.5×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×26 #40×10TS 46 41.1 12 13 W W+28 KR-605011S 60.5×3. 100~1000 SGP50A 6002ZZ 15.0 21×15.2×41.5 · 21×15.2×12 #50×11TS 63 56.35 20 18 W+3 W+48 KR-765011S 76.3×4.2 100~1000 SGP65A 6002ZZ 15.0 21×15.2×41.5 · 21×152×12 #50×11TS 63 56.35 20 18 W+2 W+48 KR-605013S 60.5×3.8 100~1000 SGP50A 6004ZZ 20.0 29×20.2×38.5 · 29×20.2×15 #50×13TS 73 66.34 20 18 W+1 W+48 KR-765013S 76.3×4.2 100~1000 SGP65A 6004ZZ 20.0 29x20.2x38.5 · 29×20.2×15 #50×13TS 73 66.34 20 18 W+2 W+48 KR-895013S 89.1×4.2 100~1000 SGP80A 6004ZZ 20.0 29×20.2x38.5 · 29×202x15 #50×13TS 73 66.34 20 18 W W+48 KR-1146014S 114.3×4.5 300~2000 SGP100A 6205ZZ 25.0 35×26×19 · 35×26×21 #60×14TS 93 85.61 20 23 W W+58 KR-1406016S 139.8×4.5 300~2000 SGP125A 6206ZZ 30.0 38×31.1×19 · 38×31.1×21 #60×16TS 107 97.65 20 23 W W+58
-
Double Row Sprocket Drive Roller
Cat:Sprocket Drive Roller
Type Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket d1 d2 A ...
See DetailsType Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket d1 d2 A B C W1 BB KR-384010SW 38.1×2.3 100~800 STKM 6001ZZ · 6201Z 12.0 18×12.2×53 #40×10TSW 46 41.1 12 23 18 W-1 W+58 KR-424010SW 42.7×2.3 100~800 STKM 6001ZZ · 6201Z 12.0 18×12.2×53 #40×10TSW 46 41.1 12 23 18 W W+58 KR-484010SW 48.6×3.5 100~800 SGP40A 6001ZZ · 6201Z 12.0 18×12.2×53 #40×10TSW 46 41.1 12 23 15 W+5 W+58 KR-504010SW 50.8×1.6 100~800 STKM 6001ZZ · 6201Z 12.0 18×12.2×53 #40x10TSW 46 41.1 12 23 18 W-1 W+58 KR-574010SW 57.1×2.1 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×53 #40×10TSW 46 41.1 12 23 18 W W+58 KR-604010SW 60.5×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×53 #40×10TSW 46 41.1 12 23 18 W W+58 KR-605011SW 60.5×3.8 100~1000 SGP50A 6002ZZ 15.0 21x15.2×66.5 · 21×15.2x12 #50×11TSW 63 56.35 20 25 18 W+3 W+73 KR-765011SW 76.3×4.2 100~1000 SGP65A 6002ZZ 15.0 21×15.2×66.5 · 21×15.2×12 #50×11TSW 63 56.35 20 25 18 W+2 W+73 KR-605013SW 60.5×3.8 100~1000 SGP50A 6004ZZ 20.0 29×20.2×63.5 · 29×20.2×15 #50×13TSW 73 66.34 20 25 18 W+1 W+73 KR-765013SW 76.3×4.2 100~1000 SGP65A 600422 20.0 29×20.2×63.5 · 29×20.2x15 #50×13TSW 73 66.34 20 25 18 W+2 W+73 KR-895013SW 89.1×4.2 100~1000 SGP80A 6004ZZ 20.0 29×20.2×63.5 · 29×20.2×15 #50×13TSW 73 66.34 20 25 18 W W+73
-
Double Row Sprocket Drive Roller
Cat:Sprocket Drive Roller
Type Roller size Rollerwidth Roller matenal Bearng Shaft diameter Sprocket d1 d2 d3 A L BB P1 P2 ...
See DetailsType Roller size Rollerwidth Roller matenal Bearng Shaft diameter Sprocket d1 d2 d3 A L BB P1 P2 P3 P4 KPR-574015SW 57.2×2.6 300~2000 STKM UCPA204 25xW+152 #40×15TSW 67 61.08 20 33 W+152 W+86 24 23 17 22 KPR-604015SW 60.5×3.8 300~2000 STKM UCPA204 25xW+152 #40×15TSW 67 61.08 20 33 W+152 W+86 24 23 17 22 KPR-765013SW 76.3×4.2 300~2000 SGP65A UCPA204 25xW+163 #50×13TSW 73 66.34 20 33 W+163 W+97 32 25 18 22 KPR-895013SW 89.1×4.2 300~2000 SGP80A UCPA206 35xW+169 #50×13TSW 73 66.34 30 39 W+169 W+91 29 25 18 19 KPR-1015018SW 101.6×4.5 300~2000 SGP90A UCPA206 35xW+169 #50×18TSW 98 91.42 30 39 W+169 W+91 29 25 18 19 KPR-1145018SW 114.3×4.5 300~2000 SGP100A UCPA206 35xW+169 #50×18TSW 98 91.42 30 39 W+169 W+91 29 25 18 19 KPR-1405018SW 139.8×4.5 300~2000 SGP125A UCPA206 35xW+169 #50×18TSW 98 91.42 30 39 W+169 W+91 29 25 18 19
-
Accumulating Roller
Cat:Accumulating Roller
Type Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket MAC-CN...
See DetailsType Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket MAC-CN384010S 38.1×2.3 100~800 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN424010S 42.7×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 18x12.2×17 #40×10TS MAC-CN484010S 48.6×3.5 100~1000 SGP40A 60012Z · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN504010S 50.8×1.6 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN574010S 57.1×2.1 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN604010S 60.5×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS Type Roller size Roller width Roller material Bearing Shaft diameter Sprocket MAC-CS384010S 38.1×2.3 100~800 STKM 6001ZZ · 6201Z 12.0 #40×10TS MAC-CS424010S 42.7×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 #40×10TS MAC-CS484010S 48.6×3.5 100~1000 SGP40A 6001ZZ · 6201Z 12.0 #40×10TS MAC-CS504010S 50.8×1.6 100~1000 STKM 6001ZZ · 6201Z 12.0 #40×10TS MAC-CS574010S 57.1×2.1 100~1000 STKM 6001ZZ · 6201Z 12.0 #40×10TS MAC-CS604010S 60.5×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 #40×10TS
-
Accumulating Roller
Cat:Accumulating Roller
Type Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket MAC-CN...
See DetailsType Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket MAC-CN384010SW 38.1×2.3 100~800 STKM 6001Z · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN424010SW 42.7×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN484010SW 48.6×3.5 100~1000 SGP40A 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN504010SW 50.8×1.6 100~1000 STKM 6001Z · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN574010SW 57.1×2.1 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS MAC-CN604010SW 60.5×2.3 100~1000 STKM 6001ZZ · 6201Z 12.0 18×12.2×17 #40×10TS
-
Accumulating Roller
Cat:Accumulating Roller
Type Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket d1 d2 ...
See DetailsType Roller size Roller width Roller material Bearing Shaft diameter Liner size Sprocket d1 d2 MAC-CN605010SW 60.5×2.3 100~1000 STKM 6002Z7 · 61902Z 15.0 20×15.2×16 #50×10TS 57.43 51.37 MAC-CN765013SW 76.3×2.0 100~1000 STKM 6204ZZ · 61904Z 20.0 25×20.2×22 #50×13TS 73 66.34
-
Tapered Drive Roller
Cat:Tapered Drive Roller
R Center 1000 Total length Roller width Wide of conveyor Narrow path Large diameter Loading of...
See DetailsR Center 1000 Total length Roller width Wide of conveyor Narrow path Large diameter Loading of roller Weight of roller Sprocket #40×10TSW (∅) Thickness (∅) Thickness W Roller width 200~600 258 200 260 51.5 3.0 62.5 2.6 1842 1236 Roller material STKM 358 300 360 48.8 3.0 65.2 2.6 1215 1643 Beaning 6001ZZ · 6201Z 458 400 460 46.0 3.1 68.0 2.6 911 2050 db Shaft diameter 12.0 558 500 560 43.3 3.2 70.7 2.4 725 2456 dC×dc×Lc/Liner size
18×12.2×53 · 18×12.2×7 658 600 660 41.3 3.3 74.0 2.3 597 2863 R Center 1200 Total length Roller width Wide of conveyor Narrow path Large diameter Loading of roller Weight of roller Sprocket #40×10TSW (∅) Thickness (∅) Thickness W Roller width 200~600 258 200 260 52.1 2.9 61.9 2.5 1842 1.132 Roller material STKM 358 300 360 49.7 3.0 64.3 2.4 1215 1487 Beaning 6001ZZ · 6201Z 458 400 460 47.3 3.1 65.7 2.4 911 1842 db Shaft diameter 12.0 558 500 560 45.0 3.2 69.2 2.8 725 2197 dC×dc×Lc/Liner size 18×12.2×53 · 18×12.2×7 658 600 660 45.0 3.2 74.0 2 597 2552 R Center 1500 Total length Roller width Wide of conveyor Narrow path Large diameter Loading of roller Weight of roller Sprocket #40×10TSW (∅) Thickness (∅) Thickness W Roller width 200~600 258 200 260 52.6 2.7 61.4 2.8 1842 1233 Roller material STKM 358 300 360 50.4 2.9 63.6 2.7 1215 1645 Beaning 6001ZZ · 6201Z 458 400 460 48.0 3.1 65.4 2.4 911 2046 db Shaft diameter 12.0 558 500 560 48.0 3.4 69.8 2.4 725 2452 dC×dc×Lc/Liner size 18×12.2×53 · 18×12.2×7 658 600 660 48.0 3.1 74.0 2.1 597 2.86 R Center 2000 Total length Roller width Wde of conveyor Narrow path Large diameter Loading of roller Weight of roller Sprocket #40×10TSW (∅) Thickness (∅) Thickness W Roller width 400~800 458 400 460 50.0 3.0 62.5 2.3 911 1990 Roller material STKM 558 500 560 50.0 3.0 65.6 2.2 725 2398 Beaning 6001ZZ · 6201Z 658 600 660 50.0 3.0 68.8 2.2 597 2797 db Shaft diameter 12.0 758 700 760 50.0 3.0 71.9 2.1 519 3210 dC×dc×Lc/Liner size 18×12.2×53 · 18×12.2×7 858 800 860 50.0 3.0 75.0 2.0 450 3620
-
Tapered Drive Roller
Cat:Tapered Drive Roller
R Center 500 Total length Roller width Wide of conveyor Narrow path Large diameter Sprocket #...
See DetailsR Center 500 Total length Roller width Wide of conveyor Narrow path Large diameter Sprocket #40×10TSW (∅) (∅) W Roller width 300~700 328 300 330 42.7 60 Roller material STKM 428 400 430 42.7 65 Beaning 6001ZZ · 6201Z 528 500 530 42.7 75 db Shaft diameter 12.0 628 600 630 42.7 80 dC×dc×Lc/Liner size 18×12.2×27 · 18×12.2×7 728 700 730 42.7 89 R Center 900 Total length Roller width Wide of conveyor Narrow path Large diameter Sprocket #40×10TSW (∅) (∅) W Roller width 300~700 328 300 330 42.7 56 Roller material STKM 428 400 430 42.7 60 Beaning 6001ZZ · 6201Z 528 500 530 42.7 65 db Shaft diameter 12.0 628 600 630 42.7 70 dC×dc×Lc/Liner size 18×12.2×27 · 18×12.2×7 728 700 730 42.7 75 R Center 900 Total length Roller width wide of conveyor Narrow path Large diameter Sprocket #40×10TSW (∅) (∅) W Roller width 800~1000 828 800 830 42.7 65 Roller material STKM 928 900 930 42.7 70 Beaning 6001ZZ · 6201Z 1028 1000 1030 42.7 75 db Shaft diameter 12.0 dC×dc×Lc/Liner size 18×12.2×27 · 18×12.2×7
-
Polyvee Pulley Roller
Cat:Poly vee Pulley Roller
Type Roller size Roller width Roller material Bearing Shaft diameter Polyvee pulley DQR-3812 38...
See DetailsType Roller size Roller width Roller material Bearing Shaft diameter Polyvee pulley DQR-3812 38.1×12 100~1000 STKM 6001ZZ 12.0 Q235 DQRS-3815 38.1×1.5 100~1000 SUS304/201 6001ZZ 12.0 Q235/SUS DQR-5015 50.8×1.5 100~1000 STKM 6002ZZ 12.0 Resin DQRS-5015 50×1.5 100~1000 SUS304/201 6002ZZ 12.0 Resin DQR-5721 57.2×2.1 100~1000 STKM 6001ZZ 12.0 Q235 DQR-6023 60.5×2.3 100~1000 STKM 6002ZZ 12.0 Q235 DQRS-6020 60×2.0 100~1000 SUS304/201 6002ZZ 12.0 Q235/SUS/Resin DQR-7620 76.3×2.0 100~1000 STKM 6001ZZ 12.0 Q235 DQRS-7620 76×2.0 100~1000 SUS304/201 6001ZZ 12.0 Q235/SUS
